侏催 樫雁 mm 減塞 KN 嶷楚 kg

d D B C dk R1s R2s α 強 床




  min min 「 C C0
GE15FW2RS 15 30 16 10 25 0.3 0.3 16 22.4 56 0.046
GE17FW2RS 17 35 20 12 29 0.3 0.3 19 31.5 78 0.078
GE20FW2RS 20 42 25 16 35.5 0.6 0.6 17 51 127 0.15
GE25FW2RS 25 47 28 18 40.7 0.6 0.6 17 65.5 166 0.19
GE30FW2RS 30 55 32 20 47 0.6 1 17 210 350 0.29
GE35FW2RS 35 62 35 22 53 0.6 1 16 277 462 0.39
GE40FW2RS 40 68 40 25 60 0.6 1 17 360 600 0.52
GE45FW2RS 45 75 43 28 66 0.6 1 15 442 737 0.68
GE50FW2RS 50 90 56 36 80 0.6 1 17 690 1150 1.4
GE60FW2RS 60 105 63 40 92 1 1 17 885 1475 2
GE70FW2RS 70 120 70 45 105 1 1 16 1125 1875 2.9
GE80FW2RS 80 130 75 50 115 1 1 14 1380 2300 3.5
GE90FW2RS 90 150 85 55 130 1 1 15 1717 2862 5.4
GE100FW2RS 100 160 85 55 140 1 1 14 1845 3075 6
GE110FW2RS 110 180 100 70 160 1 1 12 2685 4475 9.7
GE120FW2RS 120 210 115 70 180 1 1 16 3015 5025 14
GE140FW2RS 140 230 130 80 200 1 1 16 3840 6400 19
GE160FT2RS 160 260 135 80 225 1.1 1.1 16 4320 7200 24.7
GE180FT2RS 180 290 155 100 250 1.1 1.1 14 6000 10000 35.9
GE200FT2RS 200 320 165 100 275 1.1 1.1 15 6600 11000 45.3
GE220FT2RS 220 340 175 100 300 1.1 1.1 16 7200 12000 51.1
GE240FT2RS 240 370 190 110 325 1.1 1.1 15 8550 14250 65.1
GE260FT2RS 260 400 205 120 350 1.1 1.1 15 10050 16750 82.4
GE280FT2RS 280 430 210 120 375 1.1 1.1 15 10800 18000 97.2
